Butt fusion welding machine

I'm a paragraph. Click here to add your own text and edit me. It’s easy. Just click “Edit Text” or double click me and you can start adding your own content and make changes to the font. Feel free to drag and drop me anywhere you like on your page. I’m a great place for you to tell a story and let your users know a little more about you.

GAMMA 160

GAMMA 160
Gamma 160.

GAMMA 160 is a portable butt welding machine for HDPE and PP pipes up to Ø 160 mm. GAMMA 160 features special jaws for manufacturing elbows.Machine can also weld moulded fittings like bends, tees, wyes (Y) and flange necks up to Ø160 mm; short flange necks can be welded with the help of a stub end holder (on request), applied to the clamps.Machine body of GAMMA 160 is compact and easy to transport.



STANDARD COMPOSITION:
- A machine body with pressure regulating device of the bench vice closure
- A steel frame for the support of the machine body
- Steel sliding clamps with fast closing system
- An heating plate with an electronic temperature control device
- An electrically controlled milling cutter for levelling the ends of the pipe and/or fitting, with safety micro-switch against accidental starters
- A support for the milling cutter and the heating plate
- Steel adapters  Ø 40, 50, 63, 75, 90, 110, 125, 140 mm
- A case for the adapters

ON REQUEST (ACCESSORIES)
- Tool for flange necks



BASIC 160

basic 160
Self-aligning hydraulic butt fusion machine, suitable for welding underpressure pipes for water, gas and other fluids up to Ø 160 mm.
BASIC 160 is able to weld fittings such as elbows, tees, Y-branches and flange necks without any additional equipment by simply fixing the clamps’ drag bar.
Available in 110 V; 230 V.







  • Job site self aligning hydraulic butt fusion machine
  • Working range: Ø 40 - 160 mm
  • Inserts
  • Machine Body with 4 clamps and 2 hydraulic cylinders with fast non-drip couplings
  • Heating plate with DIGITAL DRAGON, high-precision electronic  thermo-regulator
  • Extractable milling cutter, with safety micro-switch
  • Electro-hydraulic gearcase, with a clamp opening and closing lever
  • Hydraulic hoses with non – drip quick couplings.

    Standard set includes inserts from Ø 40 to 140 mm.

BASIC 200

basic 160

Self-aligning hydraulic butt fusion machine, suitable for welding underpressure pipes for water, gas and other fluids up to Ø 200 mm.

200 BASIC is able to weld fittings such as elbows, tees, Y-branches and flange necks without any additional equipment by simply fixing the clamps’ drag bar.

Available in the 230 V.




  • Job site self aligning hydraulic butt fusion machine
  • Working range: Ø 63 - 200 mm
  • SMARTLock inserts
  • Machine Body with 4 clamps and 2 hydraulic cylinders with fast non-drip couplings;
  • Heating plate with DIGITAL DRAGON, high - precision electronic thermo-regulator;
  • Extractable milling cutter, with safety micro-switch;
  • Electro-hydraulic gearcase, with a clamp opening and closing lever
  • Hydraulic hoses with non – drip quick couplings. Standard set includes adapters, from Ø 63 to 180 mm.

BASIC 250

basic 250

Self-aligning hydraulic butt fusion machine, suitable for welding underpressure pipes for water, gas and other fluids up to Ø 250 mm.

BASIC 250 is able to weld fittings such as elbows, tees, Y-branches and flange necks without any additional equipment by simply fixing the clamps’ drag bar.

Available in the 230 V.



  • Job site self aligning hydraulic butt fusion machine

  • Working range: Ø 75 - 250 mm

  • SMARTLock inserts

  • Machine Body with 4 clamps and 2 hydraulic cylinders with fast non-drip couplings

  • Heating plate with DIGITAL DRAGON, high-precision electronic thermo-regulator

  • Extractable milling cutter, with safety micro-switch

  • Electro-hydraulic gearcase, with a clamp opening and closing lever

  • Hydraulic hoses with non – drip quick couplings.

    Standard set includes adapters, from Ø 75 to 225 mm.ON REQUEST (ACCESSORIES)

  • Tool for flange necks;

  • Trolley.

BASIC 315

basic 315
Self-aligning hydraulic butt fusion machine, suitable for welding underpressure pipes for water, gas and other fluids up to Ø 315 mm. BASIC 315 is able to weld fittings such as elbows, tees, Y-branches and flange necks without any additional equipment by simply fixing the clamps’ drag bar. Available in 230 V.



  • Job site self aligning hydraulic butt fusion machine
  • Working range: Ø 90 - 315 mm
  • SMARTLock inserts
  • Machine Body with 4 clamps and 2 hydraulic cylinders with fast non-drip couplings
  • Heating plate with DIGITAL DRAGON, high-precision electronic  thermo-regulator
  • Extractable milling cutter, with safety micro-switch
  • Electro-hydraulic gearcase, with a clamp opening and closing lever
  • Hydraulic hoses with non – drip quick couplings.

    Standard set includes inserts from Ø 90 to 280 mm with 250 mm and Master adapters.
     ON REQUEST (ACCESSORIES)
  • Tool flange necks;
  • Trolley.

BASIC 355

basic 355
Self-aligning hydraulic butt fusion machine, suitable for welding underpressure pipes for water, gas and other fluids up to Ø 355 mm.
BASIC 355 is able to weld fittings such as elbows, tees, Y-branches and flange necks without any additional equipment by simply fixing the clamps’ drag bar.
Available in 230 V.



  • Job site self aligning hydraulic butt fusion machine

  • Working range: Ø 125 - 355 mm

  • Machine Body with 4 clamps and 2 hydraulic cylinders with fast non-drip couplings

  • Heating plate with DIGITAL DRAGON, high-precision electronic  thermo-regulator

  • Extractable milling cutter, with safety micro-switch

  • Electro-hydraulic gearcase, with a clamp opening and closing lever

  • Hydraulic hoses with non – drip quick couplings.



    Standard set includes inserts from Ø 125 to 315 mm with 250 mm Master adapters.

     ON REQUEST (ACCESSORIES)

    •  Tool for flange necks;

  • Trolley.
